Features
◇ Filter dust and other small particles from the entry port.
◇ Transparent housing, easy to indicate degree of contamination.
◇ It can be connected directly to the vacuum port of vacuum pump, such as ABM and ABX, etc.
◇ Inline vacuum filter has compact structure and small size, economic and environmental protective.
Application
◇ Suitable for vacuum system with light or medium dirt level.
| How to order | ||||
| ZFL 06 ① ② | ||||
| ① Series | ② Port Size | |||
| ZFL | 06 - Φ6 hose（Direct-insert type） 10 - G3/8 Male thread | |||
| Technical parameters | |||||||
| Model | Operating pressure (kPa) | Material | Temperature (℃) | Removal efficiency (μm) | Nominal flow (NL/min) | Internal volume (cm3) | Weight (g) |
| ZFL06 | -100~0 | PP PE | 0-80 | 20-25 | 25 | 4 | 3.5 |
| ZFL10 | 220 | 20 | 13 | ||||
